Name: China Water Cooled Condensing Unit with Scroll Compressor Manufacturers Suppliers Factory
Brand: ZHEXUE
SKU: 228545644

Water Cooled Condensing Unit with Scroll Compressor

The water cooled condensing unit with scroll compressor is a highly efficient refrigeration system that utilizes multiple compressors in parallel to share the exhaust manifold, suction manifold, condenser, liquid storage tank and other components, thereby forming a highly efficient refrigeration cycle system. With a large cooling capacity and centralized control, the unit is the ideal solution for a wide range of industrial cooling needs.

Water cooled condensing unit with scroll compressor

Installation location:

Please choose the suitable installation location as follows:

1.The unit must be installed outside the building in a location with good ventilation and smooth exhaust, and should be installed on level ground and a solid support.

2.The condensing unit and the air cooler should be as close to each other as possible to minimize the height difference between the compression condensing unit and the air cooler and the number of elbows in the pipes.

3.Avoid placing the condensing unit under a window or between buildings, or operating noise will be transmitted indoors.

4.There should be no strong heat sources, exhaust outlets of other equipment, steam and flammable gases around the unit.

5.There should be appropriate space around the unit for normal operation and maintenance. Rubber pads should be added between the frame and the support during installation to reduce the spread of vibration.
