9HP Box Type Monoblock Refrigeration Condensing Unit
Zhexue 9HP Box Type Monoblock Refrigeration Condensing Unit is designed for small size cold storage, its all-in-one figure has simplified the installation process, and due to its low budget it has become one of our best-selling products.
This unit adopts U-type air-cooled condensers, and it's usually used in medium and low temperature working conditions (-18℃~+10℃).
Engineered for versatility, they are commonly used in telecom shelters, server rooms, medical equipment cooling, and small-scale HVAC systems. Their modular design allows for flexible installation while maintaining energy efficiency through advanced components like scroll compressors and EC fans.
Constructed with corrosion-resistant materials, these units ensure reliable operation in diverse environments. The all-in-one cabinet design minimizes field assembly requirements, making them a cost-effective choice for decentralized thermal management applications where space and efficiency are critical.
Features
Space-Saving Design: Integrated components (compressor, condenser, evaporator) in a single enclosure minimize footprint, ideal for tight installations.
Energy Efficiency: Equipped with inverter-driven compressors and optimized airflow for reduced power consumption.
Low Noise: Soundproof insulation and vibration-damping materials ensure quiet performance (<50 dB).
Easy Maintenance: Front-access panels and modular components simplify servicing.
Durability: Corrosion-resistant coatings and robust construction suit harsh environments.
Smart Controls: Optional IoT connectivity for remote monitoring and diagnostics.
Widely used in HVAC, refrigeration, and telecom applications, these units balance performance, reliability, and user convenience.
Performance parameters
| MXJB series Box Type Condensing Unit with U Type Condenser | ||
| Unit model | MXJB09LBB(Y) | |
| U type condenser | MBOX018U3R | |
| Refrigerant | R22(R404A/R507A) | |
| Power supply | 380V/3P/50HZ | |
| Compressor | Model | 4TES-9Y |
| Qty | 1 | |
| condenser | Fan Qty | 1 |
| fan voltage(V) | 380 | |
| fan power (W) | 370 | |
| Evaporating Temperature | -30℃~-5℃ | |
| Evap.Temp -25℃ |
Coolingcapacity(KW) | 9.25 |
| Power input(KW) | 5.78 | |
| Running current(A) | 10.5 | |
| Liquid pipe(mm) | Φ12 | |
| Suction pipe(mm) | Φ35 | |
| Overall size | L(mm) | 850 |
| W(mm) | 750 | |
| H(mm) | 660 | |
| Cooling capacity and input power are calculated @ T.c 45℃, Suitable for air-cooled condenser. | ||
Note:
In addition to the above-mentioned specifications and requirements, our company is capable of providing customized products in order to satisfy customer needs, and refrigeration amount and power are set based on condensing temperature of 45℃, suitable for air-cooled condenser.
